Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
Ürün ayrıntıları:
| Menşe yeri: | Çin |
| Marka adı: | OSMANUV |
| Sertifika: | ISO9001 |
| Model numarası: | OSM-FM-1320 |
| Belge: | film Lamintaing.pdf |
Ödeme & teslimat koşulları:
| Min sipariş miktarı: | 1 set |
|---|---|
| Fiyat: | negotiable |
| Ambalaj bilgileri: | Ahşap ambalajı |
| Teslim süresi: | 40 gün |
| Ödeme koşulları: | T/T |
| Yetenek temini: | Müzakere |
|
Detay Bilgi |
|||
| Ürün adı: | Yüksek verimliliğe sahip mobilya tahtası aşınmaya dayanıklı film laminasyon üretim hattı | Gerilim: | 380V, 220V, 220V/110V, 380V/50Hz, 380V/220V |
|---|---|---|---|
| Durum: | Yeni | Garanti: | 1 yıl |
| Tip: | Laminasyon makinesi, fabrika tam otomatik film termal laminasyon makinesi | Uygulama: | Makine ve donanım, emtia, tıbbi, kimyasal, gıda |
| Güç: | 12KW, 50KW, 3KW, 2.5KW, 220V 50Hz | ||
| Vurgulamak: | furniture board laminating machine with warranty,wear-resistant film laminating production line,high efficiency film laminating machine |
||
Ürün Açıklaması
Furniture Board Wear-Resistant Film Laminating Production Line with High Efficiency
1. Composition of Production Line
- Automatic board loading/unloading system
- Surface pretreatment unit (cleaning/plasma treatment)
- Precision adhesive application system
- High-pressure film laminating unit
- CNC trimming and edge finishing system
- Quality inspection with vision system
- Centralized PLC control with IoT connectivity
2. Product Description
This automated film laminating production line specializes in applying wear-resistant decorative films to various furniture boards (MDF, particle board, plywood). It ensures perfect film adhesion with scratch and stain resistance, making it ideal for high-quality furniture manufacturing.
3. Technical Parameters:
| Parameter Category | Specification | Notes |
|---|---|---|
| Max. Board Width | 0-1320 mm | Customizable to specific requirements |
| Production Speed | 1-20 m/min | Adjustable based on material |
| Laminating Accuracy | ±0.15 mm | Laser guiding system |
| Operating Pressure | 50-150 tons | Customizable pressure settings |
| Temperature Control | 50-200°C ±1°C | PID precision control |
| Power Requirement | 380V/50Hz/100kW | Customizable voltage options |
4. Application
- Office furniture manufacturing
- Kitchen cabinet production
- Wardrobe and storage systems
- Commercial furniture applications
5. Customization
- Width Options: Customizable from 600mm to 2800mm
- Film Compatibility: Adaptable for PVC, PP, PET, decorative films
- Automation Level: From semi-auto to fully robotic systems
- Special Features: Optional embossing or texture patterns
6. Feature
- High Efficiency: Automatic feeding and stacking systems
- Precision Control: CNC-controlled temperature and pressure
- Quality Assurance: Integrated vision inspection system
- Energy Saving: Heat recovery system reduces energy consumption
7. Support and Services
- Installation and commissioning supervision
- Comprehensive operator training
- 24/7 technical support with remote monitoring
- 18-month warranty on main components
8. Packing and Shipping
- Heavy-duty export packaging
- Weatherproof wooden crates
- Professional logistics planning
- Worldwide shipping available
9. FAQ
- Q: What is the minimum order quantity?
A: We provide customizable solutions from single machines to complete production lines. - Q: Can the line handle different board materials?
A: Yes, the system is customizable for MDF, particle board, plywood, and other substrates.
